Thermosel®

Features

Compatible with standard Magnetic Coupling Option Direct Temperature Control
AMETEK Brookfield Viscometers The Thermosel is also available to Possible with DV2T/DVNext
and DVNext Rheometers purchase with a magnetic spindle Rheometer
Note: Requires optional cable coupling system. This option allows
(HT-106) spindles to be quickly attached and Computer Controlled when used
removed, and may also help with RheocalcT Software
Provides control of sample prevent against damage that can
temperature up to +300°C occur from frequent spindle Temperature Ramping
changes or multiple users between set points is possible if
Programmable Temperature used with RheocalcT Software
Controller offers single set point Thermo Container
or up to 10 programmable set points (Heating Chamber)

Thermosel Viscosity Ranges cP(mPa•s)

SPINDLE SC4-18 SC4-31 SC4-34 SC4-21 SC4-27* SC4-28 SC4-29 HT-DIN-81**
SAMPLE VOLUME 8mL 10mL 9.5mL 8mL 10.5mL 11.5mL 13mL 7mL
SHEAR RATE (sec-1)† 1.32N .34N .28N .93N .34N .28N .25N 1.29N
MODEL
DV3TLV/DVNextLV 1.2-30K .12-300K 24-600K It is possible to use the above spindles with any of 1.0-10K
DV2TLV 1.5-30K 15-300K 30-600K these instruments. However, it is not recommended. 3.4-10K
Digital Viscometers/Rheometers will automatically
DV1LV 3-10K 30-100K 60-200K 3.4-10K
calculate viscosity. Please contact AMETEK
DVELV 3-10K 30-100K 60-200K Brookfield or an authorized dealer if you require 3.4-10K
information on viscosity range.
LVT 5-10K 50-100K 100-200K 5.7-10K
DV3TRV/DVNextRV 20-500K 100-2.5M 200-5M 400-10M 14.6-10K
DV2TRV 25-500K 125-2.5M 250-5M 500-10M 36.5-10K

DV1RV 50-170K 250-830K 500-1.7M 1K-3.3M 36.5-10K

DVERV It is possible to use the above 50-170K 250-830K 500-1.7M 1K-3.3M 36.5-10K
RVT spindles with any of these 50-100K 250-500K 500-1M 1K-2M 36.5-10K
instruments. However, it is not
DV3THA/DVNextHA 40-1M 200-5M 400-10M 800-20M 29.2-10K
recommended. Digital Viscometers/
DV2THA Rheometers will automatically 50-1M 250-5M 500-10M 1K-20M 73.0-10K
DV1HA calculate viscosity. Please contact 100-300K 500-1.7M 1K-3.3M 2K-6.7M 73.0-10K
DVEHA AMETEK Brookfield or an 100-300K 500-1.7M 1K-3.3M 2K-6.7M 73.0-10K
authorized dealer if you require
HAT 100-200K 500-1M 1K-2M 2K-4M 73.0-10K
information on viscosity range
DV3THB/DVNextHB 160-4M 800-20M 1.6K-40M 3.2K-80M 116.8-10K
DV2THB 200-4M 1K-20M 2K-40M 4K-80M 292.0-10K
DV1HB 400-1.3M 2K-6.7M 4K-13.3M 8K-26.7M 292.0-10K
DVEHB 400-1.3M 2K-6.7M 4K-13.3M 8K-26.7M 292.0-10K
HBT 400-800K 2K-4M 4K-8M 8K-16M 292.0-10K

M = 1 million K = 1 thousand N = RPM e.g. Spindle SC4-18 1.32 x 10 (rpm) = 13.2 sec-1 cP = Centipoise mPa•s = Millipascal•seconds.
N/A = Not applicable for historical reasons. However, it is possible to use any spindle/chamber combination with any torque range.
Digital viscometers/rheometers will automatically calculate viscosity.
