Page 16 - AMETEK BROOKFIELD Viscometer

Small Sample Adapter™

Small Sample Adapter Viscosity Ranges cP(mPa•s)

(316 s/s only)
SPINDLE SC4-18 SC4-31 SC4-34 SC4-16 SC4-25Z SC4-21 SC4-27(D) SC4-15 SC4-28 SC4-29 SC4-14
SAMPLE CHAMBER *SC4-13R(P) *SC4-13R(P) *SC4-13R(P) *SC4-8R(P) *SC4-13R(P) *SC4-13R(P) *SC4-13R(P) *SC4-7R(P) *SC4-13R(P) *SC4-13R(P) *SC4-6R(P)
SAMPLE VOLUME 6.7mL 9.0mL 9.4mL 4.2mL 16.1mL 7.1mL 10.4mL 3.8mL 11.0mL 13.5mL 2.1mL
SHEAR RATE (sec-1) 1.32N .34N .28N .29N .22N .93N .34N .48N .28N .25N .40N
MODEL

DV3TLV/DVNextLV 1.2-30K 12-300K 24-600K 48-1.2M 192-4.8M
It is possible to use the above spindles with any of these
DV2TLV 1.5-30K 15-300K 30-600K 60-1.2M 240-4.8M instruments. However, it is not recommended. Digital

DV1LV 3-10K 30-100K 60-200K 120-400K 800-1.6M Viscometers/Rheometers will automatically calculate viscosity.

DVELV 3-10K 30-100K 60-200K 120-400K 800-1.6M Please contact AMETEK Brookfield or an authorized dealer if
you require information on viscosity range.
LVT 5-10K 50-100K 100-200K 200-400K 800-1.6M
DV3TRV/DVNextRV 20-500K 100-2.5M 200-5M 200-5M 400-10M 500-12.5M
DV2TRV 25-500K 125-2.5M 250-5M 250-5M 500-10M 625-12.5M

DV1RV 50-170K 250-830K 500-1.7M 500-1.7M 1K-3.3M 1.25K-4.2M
DVERV 50-170K 250-830K 500-1.7M 500-1.7M 1K-3.3M 1.25K-4.2M

RVT 50-100K 250-500K 500-1M 500-1M 1K-2M 1.25K-2.5M
It is possible to use the above spindles
DV3THA/DVNextHA with any of these instruments. However, 40-1M 200-5M 400-10M 400-10M 800-20M 1K-25M
it is not recommended. Digital
DV2THA 50-1M 250-5M 500-10M 500-10M 1K-20M 1.25K-25M
Viscometers/Rheometers will
DV1HA automatically calculate viscosity. Please 100-300K 500-1.7M 1K-3.3M 1K-3.3M 2K-6.7M 2.5K-8.3M

DVEHA contact AMETEK Brookfield or an 100-300K 500-1.7M 1K-3.3M 1K-3.3M 2K-6.7M 2.5K-8.3M
authorized dealer if you require
HAT 100-200K 500-1M 1K-2M 1K-2M 2K-4M 2.5K-5M
information on viscosity range.
DV3THB/DVNextHB 160-4M 800-20M 1.6K-40M 1.6K-40M 3.2K-80M 4K-100M

DV2THB 200-4M 1K-20M 2K-40M 2K-40M 4K-80M 5K-100M

DV1HB 400-1.3M 2K-6.7M 4K-13.3M 4K-13.3M 8K-26.7M 10K-33.3M

DVEHB 400-1.3M 2K-6.7M 4K-13.3M 4K-13.3M 8K-26.7M 10K-33.3M

HBT 400-800K 2K-4M 4K-8M 4K-8M 8K-16M 10K-20M

M = 1 million K = 1 thousand N = RPM e.g. Spindle SC4-18 1.32 x 10 (rpm) = 13.2 sec-1 cP = Centipoise mPa•s =
Millipascal•seconds. N/A = Not applicable for historical reasons. However, it is possible to use any spindle/chamber
combination with any torque range. Digital viscometers/rheometers will automatically calculate viscosity.

* Examples
SC4-13R Sample Chamber SC4-13RP Sample Chamber with RTD temperature
SC4-13RPY Sample Chamber with RTD temperature probe
probe and cable to viscometer/rheometer SC4-13RD-100 Disposable Sample Chamber available in
SC4-27 Stainless Steel Spindle packages of 100
† Disposable chamber available in 13R size and requires SC4-27D Disposable Spindle
SC4-45YD water jacket Note: Hastelloy C available for some spindles/chambers.
Call for details.
